SG90 Mini Gear Micro Servo 9g
Code: BCE.006
SG90 9g micro servo motor for lightweight builds such as a cnc writer. It connects easily to Arduino and is controlled via PWM, with 1kg/cm torque (4.8V) and an operating voltage of 3.0V~7.2V.
3,10 €
Includes 24% VAT
- Free shipping over 100,00 €
- Pickup in Patras (by appointment)
- Secure payments
- Technical support
Categories: Motors & Servos
Description
DESCRIPTION
Small servo motor for light builds such as a cnc writer. Easy to connect to Arduino.
FEATURES
- Dimensions: 22mm x 11.5mm x 22.5mm
- Operating speed: 0.12second/ 60degree ( 4.8V no load)
- Torque (4.8V): 17.5oz /in (1kg/cm)
- Temperature range: -30 to +60
- Dead band width: 7usec
- Operating voltage: 3.0V~7.2V
WIRING
Red (5V)
Brown (GND)
Orange (PWM)
Specifications
- Password
- BCE.006
- Brand
- OEM
- Weight
- 0.07 kg
